T4301N22TOF
search
  • T4301N22TOF
  • T4301N22TOF

T4301N22TOF

$ 970,20
Sem imposto

VARIOS

Última actualización

DatasheetT4301N22TOF

4030A/2200V/1U

No identificado

Delivery time :

Quantidade
Esgotado

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • PHASE CONTROL THYRISTOR
  • Full blocking 50/60HZ over a widw range temperature range
  • High DC blocking stability
  • High surge current capability
  • High case non-rupture current
  • High di/td capability

Aplications

  • Applications
  • Static Var Compensation SVC
  • High Current Rectifier
  • Rectifier for Drives Applications
  • Welding
  • Crowbar Applications

Infineon, Formerly Eupec Phase Control SCRs, T4301N Series

Infineon, Formerly Eupec

T4301N22TOF

SCR ; Package Style; TO-200AJ

Vrrm (volts); 2200 Volts

Vdrm (volts); 2200 Volts

It (rms) Amps; 9420 Amps

It (avg) Amps; 4300 Amps

Itsm Amps; 100000 Amps

di/dt (A/microseconds); 300

dv/dt (V/microseconds); 1000

I2T@50Hz (A2Sec); 50000000

Vtm (volts); 1.2 Volts

tq (microseconds); 250 MicroSeconds

Irrm Peak (mA); 600 MilliAmps

Idrm Peak (mA); 600 MilliAmps

Igt (mA); 300 MilliAmps

Vgt (volts); 2.5 Volts

Puck Size (h x dia.) in.; 1.38x6

Junction Temp.; 257 Degrees F

Mounting Force; 63~91 kN

RoHS; Yes

Diag. No.; EUPC_SCR_DIAG_T150.35K

T4301N22TOF
