71HF120
$10.40
No tax
71HF120
Política de seguridad
(Our products have limited warranty, please check our terms)
Política de entrega
(Delivery 1-2 days for products in stock)
Features
- STu00c3u0081NDAR RECOVERY DIODES
- High surge current capability
- Designed for a wide range of applications
- Stud cathode and stud anode version
- Leaded version available
- Type up to 1600V VRRM
Aplications
- Applications
- Battery charges
- Converters
- Power supplies
- Machine tool controls
Vishay Standard Recovery Diodes, 71HF Series
Vishay
71HF120
DIODE, DO-5L, 1200V, 70A, FWD, STD ; Polarity; Cathode Stud (Forward)
Vrrm (volts); 1200 Volts
IF (rms) Amps; 110 Amps
IF (avg) Amps; 70 Amps
Ifsm Amps; 1250 Amps
I2T@60Hz (A2Sec); 6450
I2T@50Hz (A2Sec); 7100
Vfm (volts); 1.35 Volts
Junction Temp.; -85~356 Degrees F
Mounting Force; 30 lbf-inches
Stud Size; 1/4-28 UNF-2A
Lead Type; Flexible
Lead Length FMS (inches); 4.84 Inches
RoHS Compliant; Yes ;
71HF120
Specific References
- MPN
- 71HF120
