- Out-of-Stock
SKN45/04
$13.86
No tax
SKN45/04
Política de seguridad
(Our products have limited warranty, please check our terms)
Política de entrega
(Delivery 1-2 days for products in stock)
Features
- Rectifier Diode
- Reverse voltage up to 1600 V
- Hermetic metal cases with glass insulators
- Threaded studs ISO M8(SKN/R 71 also 1/4- 28UNF)
- SKN : anode to stud
- SKR : cathode to stud
Aplications
- Applications
- All-purpose mean power rectifier diodes
- Cooling via heatsinks
- Non-controllable and
- half-controllable rectifiers
- Free-wheeling diodes
- Recommended snubber
- network : RC: 0.1uF, 100 Ohms (pR = 1 W) Rp = 80 Kohms (PR = 6 W)
Semikron Standard Recovery Diodes, SKN45 Series
Semikron
SKN45/04
DIODE, M8LIL, 400V, 45A, REV, STD, M8X1.25, 135mm FMS ; Package Type; Case E 12
Polarity; Anode Stud (Reverse)
Vrrm (volts); 400 Volts
IF (rms) Amps; 80 Amps
IF (avg) Amps; 45 Amps
Ifsm Amps; 700 Amps
I2T@60Hz (A2Sec); 2500
I2T@50Hz (A2Sec); 2500
Vfm (volts); 1.6 Volts
Junction Temp.; 356 Degrees F
Mounting Force; 35.4 lbf-in
Stud Size; M8 x 1.25
Lead Type; Flexible Insulated Yellow
Lead Length FMS (inches); 5.31 Inches ;
SKN45/04
Specific References
- MPN
- SKN45/04
