PM150CSE060

INTELLIGENT POWER MODULE

Adopting new 4th generation planar IGBT chip, which performance is improved by 1um fine rule process. For example, typical VCE(sat)=1.7V

Using new Diode which is designed to get soft reverse recovery haracteristics

3 phase 150A, 600V Current-sense IGBT for 15kHz switching

Monolithic gate drive & protection logic

Detection, protection & status indication circuits for over-current, short-circuit, over-temperature &

under-voltage (P-Fo available from upper leg devices)

Acoustic noise-less 15/18.5kW class inverter application

Applications

General purpose Inverter

Servo drives

Motor control
