- Fuera de stock
PM300CLA060
472,50 $
Sin impuestos
PM300CLA060
Security policy
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Delivery policy
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIENT POWER MODULE
- a ) Adopting 5th generation IGBT (CSTBT) chips, which performance
- is improved by 1um fine rule process
- For example, typical Vce(sat) = 1.5 V @ Tj = 125u00c2u00b0C
- b )I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from each conservation upper and lower arm of IPM
- 3 phase 300A, 600V Current-sense IGBT type inverter
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for
- over-current, short-circuit, over-temperature & under-voltage (P-Fo available from upper arm devices)
- Acoustic noise-less 30kW class inverter applications
Aplications
- Applications
- Servo drives
- motor controls
Powerex Intelligent Power Module (IPM)
Powerex
PM300CLA060
IPM 300A 600V SIX-PACK
PM300CLA060
Referencias específicas
- MPN
- PM300CLA060
