PM300CLA120

INTELLIGENT POWER MODULE

a) Adopting new 5Tth generation IGBT (CSTBT) chp, which performance is improved by 1um fine rule process. For example, typical VCE(sat) =1.0V @ Tj=125 C

b) I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation upper and lower arm of IPM

3 0/ 300A, 1200V Current-sense IGBT type inverter

Monolithic gate drive & protection logic

Detection, protection & status indication circuits for, short-circuit. over-temperature & under-voltage (Fo available from all arm devices)

Acoustic noise-less 45kW/55kW class inverter applications

UL Recognized Yellow Card No. E80276(n)

File No. E80271

Applications

General purpose inverter

servo drives

motor controls
