CR2LS-75
34,13 $
Sin impuestos
CR2LS-75
Security policy
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Delivery policy
(Envíos de 1-2 días hábiles para productos de stock)
Features
- Super Rapid Fuses
- 150-1500 volts AC
- 10-4700 Amps
- The total clearing I2t is small and the semiconductor circuit
- is completely protected
- Since the peak arc voltage at the time of interruption is low
- damage to other equipment does not occur
- High interrupting capacity of 200kA of 1000V AC
Aplications
- Semiconductors High Power Equipment Repair
Fuji Japanese Fuses, CR Series
Fuji
CR2LS-75
FUSE, 75A, 250VAC, SEMI, FOOTED I2T = 2300, 100kAIC, 56mm OAL, 42mm C-C, 17.5mm DIA ; Amps; 75
Volts AC; 250
Volts DC; 400
Characteristic; Semiconductor
Package Type; Offset Bolted
Interrupt Rating; 100kA @ 250V
I2t Clearing Amps; 2300 Amps
Length (mm); 56 MilliMeters
Depth (mm); 18.5 MilliMeters
Mounting Centers (mm); 42 MilliMeters ;
CR2LS-75
Referencias específicas
- MPN
- CR2LS-75
