R2619ZC25J

Westcode Semiconductors Inverter SCRs, R Series

Westcode Semiconductors

R2619ZC25J

SCR,TO-200AF,2500V,5227A,TQ=50 ; Package Style; W13

Vrrm (volts); 2500 Volts

Vdrm (volts); 2500 Volts

It (rms) Amps; 5227 Amps

It (avg) Amps; 2619 Amps

Itsm Amps; 33800 Amps

di/dt (A/microseconds); 1000

dv/dt (V/microseconds); 200

I2T@60Hz (A2Sec); 5710000

Vtm (volts); 2 Volts

tq (microseconds); 50 MicroSeconds

Irrm Peak (mA); 300 MilliAmps

Idrm Peak (mA); 300 MilliAmps

Igt (mA); 300 MilliAmps

Vgt (volts); 3 Volts

Puck Size (h x dia.) in.; 1.48 x 4.35 inches

Junction Temp.; 257 Degrees F

Mounting Force; 26~46 kN

RoHS; Yes ;
