- Fuera de stock
Z86E0208PSC
18,38 $
Sin impuestos
Z86E0208PSC
Security policy
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Delivery policy
(Envíos de 1-2 días hábiles para productos de stock)
Features
- 512-Byte Rom MICROCONTROLLERS
- 18-Pin DIP and SOIC Packages
- 0u00c2u00b0C to 70u00c2u00b0C Stu00c3u00a1ndar Temperature -40u00c2u00b0C to
- 105u00c2u00b0C Extended Temperature (Z86C02/E02 only)
- 3.0V to 5.5V Operating Range (Z86C02)
- 4.5V to 3.9V Operating Range (Z86E02)
- 2.0V to 3.09V Operating Range (Z86L02)
- 14 Input / Output Lines
- Five Vectored, Prioritized Interrupts from Five
- Different Sources
- Two On-Board Comparators
- Software Enable Watcg-Dog Timer (WDT)
- Programmable Interrpt Polarity
- Two Stanby Modes : STOP and HALT
- Low-Voltage Protection
- ROM Mask/OTP Options :
- Low-Noise (Z86C02/E02 only)
- ROM Protect
- Auto Latch
- Permanent Watch-Dog Timer (WDT)
- RC Oscillator (Z86C02/L02 Only)
- 32 kHz Operation (Z86C02/L02 Only)
- One Programmable 8-Bit Counter/Timer with a
- 6-Bit Programmable Prescaler
- Power-On Reser (POR) Timer
- On-Chip Oscillator that Accepts RC, Crystal, Ceramic
- Resonator, LC, or External Clock Drive (C02/L02 only)
- On-Chip Oscillator that Accepts RC or External Clock
- Drive (Z86E02 SL 1903 only)
- On-Chip Oscillator that Accept Crystal, Ceramic Resonator,
- LC, or External Clock Drive (Z86E02 only)
- Clock-free WDT Reset
- Low-Power Consumtion (50mw)
- Fast Instruction Pointer (1.5us @ 8MHz)
- Fourteen Digital Inputs at CMOS Levels ; Schmitt-Triggered
Aplications
- Semiconductors High Power Equipment Repair
Z86E0208PSC
Referencias específicas
- MPN
- Z86E0208PSC
