ST180S12P0V
search
  • ST180S12P0V
  • ST180S12P0V

ST180S12P0V

132,83 $
Aucune taxe

SCR - THYRISTOR CONTROL DE FASE

Última actualización

DatasheetST180S12P0V

200A/1200V/1U

No identificado

Delivery time :

Quantité
Rupture de stock

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • PHASE CONTROL THYRISTOR
  • Center amplifying gate
  • Hermetic metal case with ceramic insulator (Also available with glass-metal seal up to 1200V)
  • International stu00c3u00a1ndar case TO-209AB (TO-93)
  • Threaded studs UNF 3/4 - 16 UNF2A or ISO M16 X 1.5
  • Compression Bonded Encapsulation for heavy duty operations such as severe thermal cycling

Aplications

  • Applications
  • DC motor controls
  • Controlled DC power supplies
  • AC controllers

Vishay Phase Control SCRs, ST Series

Vishay

ST180S12P0V

SCR, TO-93, 1200V, 200A ; Package Style; TO-93

Vrrm (volts); 1200 Volts

Vdrm (volts); 1200 Volts

It (rms) Amps; 314 Amps

It (avg) Amps; 200 Amps

Itsm Amps; 5230 Amps

di/dt (A/microseconds); 1000

dv/dt (V/microseconds); 500

I2T@60Hz (A2Sec); 114000

I2T@50Hz (A2Sec); 125000

Vtm (volts); 1.75 Volts

tq (microseconds); 100 MicroSeconds

Irrm Peak (mA); 30 MilliAmps

Idrm Peak (mA); 30 MilliAmps

Igt (mA); 150 MilliAmps

Vgt (volts); 3 Volts

Stud Size; 3/4-16 UNF-2A

Junction Temp.; -40~257 Degrees F

Mounting Force; 210 lbf-inches

ST180S12P0V

Références spécifiques

MPN
ST180S12P0V
