AQY212EH
search
  • AQY212EH
  • AQY212EH

AQY212EH

$5.25
Sin impuestos

TRANSISTORES GU-E FOTO MOS

Última actualización

DatasheetAQY212EH

0.55A/60V/1U

No identificado

Delivery time :

Cantidad
Agotado

  Política de seguridad

(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)

  Política de entrega

(Envíos de 1-2 días hábiles para productos de stock)

Features

  • GU-EPhotoMOS
  • 1. Reinforced insulation 5,000 V type
  • More than 0.4 mm internal insulation distance between inputs and outputs. Con-forms to EN41003, EN60950 (reinforced insulation).
  • 2. Compact 4-pin DIP size The device comes in a compact (W)6.4x(L)4.78x(H)3.2mm, 4-pin DIP size
  • 3. Controls low-level analog signals PhotoMOS relays feature extremely low closed-circuit offset voltage to enable control of low-level analog signals without distortion.
  • 4. High sensitivity, low ON resistance Can control a maximun 0.13 A load current with a 5 mA input current.Low ON resistance of 25 Ohms (AQYEH) Stable operation because there are no metallic contac parts.
  • 5. Low-level off state leakage current
  • The SSR has an off state leakage current of several milliamperes, whereas the PhotoMOS relay has typ. 100 pA even with the rated load voltage of 350 V (AQY210EH).

Aplications

  • Applications
  • Modem
  • Telephone equipment
  • Security equipment
  • Sensors
AQY212EH

Referencias Específicas

Nº Pieza fabricante (NPM)
AQY212EH
