- Esgotado
PM75RSD120
$ 164,06
Sem imposto
MODULOS DE POTENCIA
Última actualización
PM75RSD12075A/1200V/7U
No identificado
Delivery time :
Política de seguridad
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Política de entrega
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- a ) Adopting new 4th generation planar IGBT chip, which
- performance is improved by 1 um fine rule process
- b ) Using new Diode which is designed to get soft reverse
- recovery characteristics
- c ) Keeping the package compatibility
- The layout/position of both terminal pin and mounting hole
- is same as S-series 3rd generation IPM
- 3 o/ 75A, 1200V Current-sense IGBT for 15kHz switching
- 25A, 1200V Current-sense regenerative brake IGBT
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for over-current, short-circuit , over-temperature & under-voltage
- (P-Fo available from upper leg devices)
- Acoustic noise-less 11/15kW class inverter application
- UL Recognized Yellow Card No. E80279(N) File No. E80271
Aplications
- Applications
- General purpose inverter
- servo drives
- motor control
Powerex IPMs, Intellimod Series
Powerex
PM75RSD120
IPM 75A 1200V 7-PACK ; Ic; 75 Amps
Vces; 1200 Volts
Circuit Configuration; Three Phase Inverter with Brake ;
PM75RSD120
Referências específicas
- MPN
- PM75RSD120
