MIG10J503H
search
  • MIG10J503H
  • MIG10J503H

MIG10J503H

$35.80
No tax

MODULOS DE POTENCIA

Última actualización

DatasheetMIG10J503H

10A/500V/6U

No identificado

Delivery time :

Quantity
Out-of-Stock

  Política de seguridad

(Our products have limited warranty, please check our terms)

  Política de entrega

(Delivery 1-2 days for products in stock)

Features

  • INTELLIGENT POWER MODULE
  • The 4th generation trench gate thin wafer
  • NPT IGBT is adopted
  • FRD is built in
  • The level shift circuit by high-voltage IC
  • built in
  • The simplification of a high side driver power
  • supply is possible by the bootstrap system
  • Short Circuit Protection, Over Temperature
  • protection and the Power Supply Under Voltage
  • Protection function are built in
  • Short Circuit protection and Over Temperature
  • Protection state are outputted
  • The lower arm emitter terminal has been
  • independent by each phase for the purpose of
  • the current detection at the time of vector control
  • Low thermal resistance by adoption of original
  • high thermal conduction resin
  • Since this product is MOS structure, it should be
  • careful of static electricity in the case of handling

Aplications

  • Semiconductors High Power Equipment Repair

Toshiba * Intelligent Power Module (IPM)

Toshiba

MIG10J503H

IPM, SIX-PACK, 600V, 10A

MIG10J503H

Specific References

MPN
MIG10J503H
