- Fuera de stock
PM25CLA120
118,35 $
Sin impuestos
PM25CLA120
Security policy
(Los productos cuentan con garantía limitada, por favor revisa nuestras condiciones)
Delivery policy
(Envíos de 1-2 días hábiles para productos de stock)
Features
- INTELLIGENT POWER MODULE
- Adopting new 5th generation IGBT (CSTBT) chip, which performance is improved by 1um fine rule process
- For example, typical VDO(sat)=1.9V Tj=125 C
- I adopt the over-temperature conservation by Tj detection of CSTBT chip, and error output is possible from all each conservation upper and lower arm of IPM
- 3 0/ 25A, 1200V current-sense IGBT type inverter
- Monolithic gate drive & protection logic
- Detection, protection & status indication circuits for, short-circuit, over-temperature & under-voltage (P-Fo available from upper arm devices)
- Acoustic noise-less 3.7kW class inverter application
- UL Recognized Yellow Card No. E80276(N)
- File No. E80271
Aplications
- Applications
- General purpose inverters
- Servo drives
- Motor Controles
Powerex Intelligent Power Module (IPM)
Powerex
PM25CLA120
IPM, SIX-PACK, 1200V, 25A
PM25CLA120
Referencias específicas
- MPN
- PM25CLA120
